New Kubota KX030-4 GL HI Cabin Mini
Excavator
Class-Leading Digging Power, Intelligent Transit: High-Specification
3-Tonne Performance. The Kubota KX030-4 GL HI redefines expectations
for power and sophistication in the 3-tonne segment. Engineered as a robust,
conventional-tail excavator, it features an incredibly stable footprint and
deep digging force that outclasses everything in its weight bracket. This
premium, high-spec **HI** configuration comes fully loaded with an advanced
**Auto-Shift Travel System**, which automatically shifts between high and low
gears based on dozer load and tracking terrain for seamless site navigation.
The luxury **Full Cabin** features premium acoustics, an integrated
high-capacity heater, and dual proportional auxiliary hydraulic lines
(AUX1/AUX2) managed entirely via intuitive joystick slide switches. Outfitted
with an extended factory **Long Arm** assembly and robust **Rubber Tracks**,
the KX030-4 GL HI delivers massive reach, rapid working cycles, and precise
control for demanding utility, structural groundwork, and heavy civil
tracking.
Auto-Shift Travel
- Intelligent Gearing: Automatically shifts from high speed
(2nd) down to low speed (1st) when pushing through heavy dozer loads or
climbing inclines.
- Seamless Navigation: Eliminates manual downshifting,
keeping tracking fluid and boosting cycle times across rough job sites.
- Powerful Trailing: Delivers robust dozing and tracking
traction while riding on high-performance, surface-safe rubber
tracks.
Request a
Quote
HI-Spec Proportional AUX
- Dual Auxiliary Circuits: Features AUX1 and AUX2 lines
pre-routed to the arm end to run complex tilting, rotating, or thumbs
attachments.
- Joystick Slide Controls: Thumb-controlled proportional
switches on the joysticks ensure pinpoint control over oil flow rates.
- Constant Flow Mode: Digital menu allows you to engage
continuous flow settings for accessories like brush cutters or
augers.
Extended Long Arm Reach
- Massive Working Envelope: Factory-lengthened arm provides
outstanding ground-level reach and maximizing deep trenching
limits.
- Superior Dumping Clearance: Easily clears tall obstacles
and commercial tipper sides to streamline material loading cycles.
- Vast Breakout Strengths: Advanced hydraulic architecture
feeds uncompromised pressure to ensure high bucket digging
forces.
Deluxe Operator Cabin
- Spacious Workspace: Industry-leading step-in space, vast
legroom, and an adjustable weight-suspension seat minimize operator
fatigue.
- Panoramic Visibility: Huge glass panes provide
exceptional visibility around the conventional tail counterweight matrix.
- Kubota Anti-Theft: Safeguarded by Kubota's
Thatcham-approved, electronically coded master key engine immobilizer
setup.
Technical Specifications - Kubota KX030-4 GL
HI (High-Spec Long Arm)
| SPECIFICATION |
DETAILS |
| Operating Weight |
2,865 kg |
| Engine Model |
Kubota V1505-E4-BH-2 (Stage V Liquid-Cooled Diesel) |
| Engine Output |
17.5 kW / 24.4 PS @ 2250 rpm |
| Travel Transmission |
Auto-Shift Travel System (Automatic 1st / 2nd Gear Sensing) |
| Operator Station |
Deluxe Full Cabin with Integrated Heater (ROPS / OPG Level 1) |
| Track Configuration |
High-Performance Premium Rubber Tracks |
| Undercarriage Type |
Heavy-Duty Fixed Track Frame |
| Arm Configuration |
Factory-Extended Long Arm Variant |
| Auxiliary Hydraulics |
High-Spec Proportional AUX1 & AUX2 Lines on Joysticks |
| Max. Digging Depth |
2,870 mm |
| Max. Digging Reach |
4,760 mm |
| Max. Dumping Height |
3,310 mm |
| Bucket Breakout Force |
25.4 kN (2,590 kgf) |
| Anti-Theft Protection |
Kubota Thatcham-Approved Coded Key
Immobilizer |
| Model Code |
Configuration / Specification |
Product Code |
| KX030-4 HGL |
Canopy, Rubber Tracks, Fixed Undercarriage,
Long Arm |
RGN1613250 |
| KX030-4 HGL Hi |
Canopy, Rubber Tracks, Fixed Undercarriage,
Long Arm, Hi-Spec - Proportional Auxiliary 1&2, Auto Shift
Travel, Auto shift travel |
RGN1733250 |
| KX030-4 GL |
Cabin, Rubber Tracks, Fixed Undercarriage,
Long Arm |
RGN1623250 |
| KX030-4 GL Hi |
Cabin, Rubber Tracks, Fixed Undercarriage,
Long Arm, Hi-Spec - Proportional Auxiliary 1&2, Auto Shift
Travel |
RGN1743250 |
