New Kubota KX060-5 KWLS2F Wide Track Mini
Excavator
Unmatched Conventional Stability, Extreme Floatation & Fully
Loaded Premium Spec. The Kubota KX060-5 KWLS2F is the flagship
5.6-tonne conventional-tail-swing excavator engineered for supreme digging
depth, massive lifting capabilities, and continuous performance in severe
environments. This top-tier model features ultra-wide **550 mm Continuous Steel
Tracks** on a rigid **Fixed Undercarriage** to slash ground pressure, prevent
sinking in deep mud, marshes, and peat, and maximize over-the-side lifting
leverage. Operators enjoy absolute comfort inside the whisper-quiet, deluxe
**Air-Conditioned Cabin** while managing advanced hydraulic attachments via twin
proportional **AUX 1 & AUX 2** thumb sliders. For relentless site
productivity, this "F" specification includes a factory-installed high-speed
**Electric Refueling Pump** alongside dual **Amber & Green Flashing
Beacons** for instant Tier 1 site clearance.
550mm Wide Track Base
- Flotation Performance: Extra-wide 550mm steel tracks
reduce ground pressure for wet, marshy, or low-load surfaces.
- Unmatched Lifting Base: Wider track width provides
incredible lateral stability when swinging heavy payloads at full reach.
- Maximum Traction: Aggressive triple-grouser steel shoes
bite deep into loose soil, slippery mud, and steep slopes.
- Severe Duty Longevity: Engineered to withstand jagged
demolition rubble, forestry roots, and abrasive bedrock.
Request a Quote
Commercial Fleet Sales
- Anti-Theft System: Factory-secured with Kubota's
electronic coded-key immobilizer system.
- Gold Standard PDI: Fully prepped, calibrated, and
safety-tested by factory-trained technicians.
- Local Plant Support: Full Isle of Wight back-up for
warranty, fast parts delivery, and specialized field service.
- Asset Finance Options: Flexible business hire-purchase
and finance structures tailored to local plant operators.
Site Safety & Fuel Pump
- Amber Warning Beacon: Highly visible roof-mounted LED
strobe alerts nearby ground crew.
- Green Belt Beacon: Lights up automatically when the
operator's seatbelt is securely buckled.
- Electric Refueling Pump: High-speed pump auto-stops when
full, allowing clean, effortless refueling from ground level barrels.
- Tier 1 Compliant: Arrives ready for instant deployment
onto strictly regulated commercial worksites.
Deluxe Cab & Twin AUX
- Climate-Controlled Cabin: Fully sealed, air-conditioned
workspace keeps dust out and operator comfort at its peak.
- Twin Proportional AUX: Thumb sliders on both joysticks
enable precise, proportional control for grabs and tiltrotators.
- Extended Long Arm: Provides a class-leading 3,890 mm
maximum digging depth and 6,250 mm horizontal reach.
- 7-inch LCD Display: Intuitive control panel makes it easy
to save and adjust hydraulic flow presets for up to 5
attachments.
Technical Specifications - Kubota KX060-5
KWLS2F (Air-Con & Wide Steel Tracks)
| SPECIFICATION |
DETAILS |
| Operating Weight |
5,785 kg (Increased ground flotation) |
| Engine Model |
Kubota V2607-CR-E5 (4-Cylinder Stage V with DPF) |
| Engine Output |
35.0 kW / 47.6 PS @ 2200 rpm |
| Tail Swing Type |
Conventional Tail Swing |
| Track Configuration |
Ultra-Wide 550 mm Continuous Steel Tracks |
| Undercarriage Type |
Heavy-Duty Fixed Track Frame |
| Arm Configuration |
Extended Long Arm Edition |
| Hydraulic Auxiliaries |
Dual Proportional AUX 1 & AUX 2 Lines on Joysticks |
| Max. Digging Depth |
3,890 mm |
| Max. Digging Reach |
6,250 mm |
| Auxiliary Hydraulic Flow (AUX1) |
75.0 L/min @ 21.0 MPa (210 kgf/cm²) |
| Auxiliary Hydraulic Flow (AUX2) |
37.0 L/min @ 21.0 MPa (210 kgf/cm²) |
| Onboard Refueling Pump |
Automatic shut-off high-flow electric pump |
| Safety Indicators |
Factory-Installed Dual Beacon Kit (Amber &
Green) |
Authorized Kubota Construction
Equipment Dealer
Stubbings Bros:
Providing elite-level plant support, technical service, and genuine parts across
the Isle of Wight.
