Kubota RT220-2 Alpha Wheeled Loader
Powerful, Manoeuvrable, Versatile. The RT220-2 Alpha is a
high-performance articulated loader designed for the rigors of modern
construction and agricultural sites. Combining a powerful Stage V engine with
heavy-duty 8-tonne planetary axles, it delivers exceptional traction and a
class-leading lifting capacity of 1225kg, all while maintaining a compact
footprint.
Supreme Power
- Kubota Engine: Stage V V1505 4-cylinder diesel
(19kW).
- Drive System: 8-tonne planetary axles with 23,000 N
pulling force.
- HST: Bosch Rexroth hydrostatic transmission for precise
speed control.
- Diff-Lock: Electronically controlled differential lock on
both axles as standard.
Powerful Operation
- Lift Capacity: Robust 1225kg straight lifting
capacity.
- Max Reach: Excellent hinge pin height of 2450mm.
- Articulation: Central pivoting point allows a sharp 44°
turning angle.
- Traction: Oscillating chassis ensures all wheels stay
grounded on uneven terrain.
User-Friendly Design
- Control: Multi-function lever provides simple command of
all major functions.
- Workspace: Large legroom, adjustable suspension seat, and
tiltable steering.
- Versatility: Hydraulic quick couplers for rapid
attachment changes.
- Protection: ISO approved ROPS/FOPS canopy or full heated
cab options.
Technical Specifications
| Specification |
Kubota RT220-2 Alpha |
| Operating Weight |
2350kg (Canopy) / 2500kg (Cab) |
| Engine Power |
19 kW (26 hp) |
| Max Lifting Capacity (Straight) |
1225 kg |
| Max Height (Hinge Point) |
2450 mm |
| Overall Width (Min/Max) |
1080 mm - 1280 mm |
| Pulling Force |
23,000 N |
SKU: .NRT220-2A
