New Kubota RT250-2 Wheeled Loader
Extremely Powerful, High Reach Loading, Compact Agility. The
Kubota RT250-2 combines robust power and impressive lift performance with a
compact frame built for tight job sites. Powered by a Stage V compliant,
high-torque 26 PS (19 kW) Kubota 4-cylinder engine, this articulated loader
delivers a straight pallet fork lifting capacity of 1,100 kg and an outstanding
2,944 mm hinge-pin reach. Designed with a heavy-duty Bosch Rexroth hydrostatic
4-wheel drive system, shaft-driven 8-tonne axles, and 45° central articulation,
the RT250-2 provides maximum pushing force, exceptional stability, and smooth
material handling across construction, agricultural, and public works
applications.
Bosch Rexroth 4WD Drive
- Shaft Drive Transmission: 8-tonne heavy-duty axles with
drive shaft output deliver up to 18,000 N of pushing force.
- Kubota V1505 Engine: Clean, high-torque 1,498 cc
4-cylinder Stage V diesel engine for low noise and fuel consumption.
- Limited-Slip Differential: Auto-engaging differential
action on both axles ensures optimum traction on soft ground.
Request a Quote
2.9m Lift & Euro-Hitch
- 2,944 mm Hinge-Pin Height: Extended boom reach easily
handles high-sided trailers, hoppers, and pallet stacking.
- 1,100 kg Fork Lift Capacity: Excellent stability and
tipping load ratio for handling heavy bulk materials with ease.
- Hydraulic Euro-Hitch: Standard hydraulic locking Euro
headstock for fast, effortless attachment changes.
Compact Articulation
- 45° Steering Angle: Central pivoting chassis provides an
ultra-tight turning radius for tight yards and sites.
- Compact Frame Width: Slender 1,100 mm transport width
navigates restricted pathways without surface damage.
- Inching Control: Integrated hand throttle and inching
feature for precise travel control when running attachments.
Operator Comfort & Safety
- ROPS/FOPS Certified: High-visibility operator platform
engineered to stringent global ISO safety standards.
- Multi-Function Joystick: Ergonomic single-lever control
over travel directional switches, loader arms, and hydraulics.
- Easy Service Access: Wide-opening engine bonnet and
tilting cab option allow fast access for 500-hour maintenance
checks.
Technical Specifications - Kubota RT250-2
Wheeled Loader
| SPECIFICATION |
DETAILS |
| Operating Weight |
2,400 kg (Canopy) / 2,605 kg (Cab) |
| Engine Model |
Kubota V1505 Stage V (4-Cylinder Diesel) |
| Engine Power Output |
19 kW / 26 PS @ 2,300 rpm |
| Engine Displacement |
1,498 cc |
| Transmission Type |
Bosch Rexroth Hydrostatic 4WD (2-Speed) |
| Max Traction Force |
18,000 N |
| Max. Lift Height (Hinge Pin) |
2,944 mm |
| Lift Capacity (Fork Straight) |
1,100 kg |
| Auxiliary Hydraulic Flow |
40 L/min @ 210 bar |
| Attachment Quick-Hitch |
Hydraulic Euro-Hitch standard |
| Overall Transport Width |
1,100 mm (standard tires) |
| Overall Transport Height |
2,322 mm |
| Overall Length (with Bucket) |
4,015 mm |
| Max Travel Speed |
20 km/h |
| Safety Structures |
ROPS / FOPS Certified Canopy or Cab |
